By Newton’s laws, this net spin cannot change for an isolated system. This universal law applies equally to humans and planets. When I pulled in my arms and legs in Oxford, I abruptly reduced the distance of much of my mass from the rotation axis. This inescapably enforced an equally abrupt increase of my rotational speed – with its unfortunate consequences. The same law explains why the Earth’s rotation axis stays fixed, pointing towards the pole star, and why the length of the day, the rotation period, does not change. The rotation speed could change only if the Earth could expand or contract, but, being rigid, it cannot. (Actually, both the axis and the day do change very slowly due to the external influence of the Sun and Moon.) For rigid bodies like the Earth and a top, the effects of angular momentum are rather obvious. However, its effects are far-reaching.

A globular cluster may contain a million stars. It has no rigidity – all its stars move individually in different directions, though gravity holds the cluster together. Its angular momentum is found by choosing three mutually perpendicular axes, and calculating the net spin around each of them. These correspond exactly to the three degrees of freedom to make twists, mentioned in the previous section. However, the three axes can always be chosen in such a way that the spin about two of them is zero, and all the net spin is thus about a single axis. This axis is a kind of arrow that points in a certain direction in space. It and the net spin remain completely unchanged as time passes. In astronomy, time passes in aeons. Since the stars all move in different directions, the bookkeeping exercise that nature performs is remarkable. A deep principle is at work.

The laws of nature are seldom seen to be operating in a pure form, and are hard to recognize. Air resistance and friction distort the basic laws of mechanics. But the greatest difficulty arises because the laws involve time, and we experience only one instant at a time. If only we could see all the instants of time stretched out before us, we could see the effects of the laws of motion directly, as in some of the diagrams earlier in the book.

However, a few phenomena reveal mechanics at work in a striking fashion. They are often associated with angular momentum. The humble top is one of the best examples. Riding a bicycle is another: the reassuring way in which balance is maintained as you speed down a hill with the air rushing past you is down to the angular momentum in the spinning wheels. Once the wheels are turning fast, they have a strong tendency to keep their axis of rotation horizontal. Indeed, a child’s hoop illustrates beautifully how the rotation axis maintains a fixed direction. So does the frisbee, spinning true as it floats through the air. Much grander examples occur naturally. I have already mentioned the earth’s rotation, which we see as the rising and setting of the Sun, Moon and stars and their ceaseless march across the sky. Many of our images of time come from this phenomenon, the child’s top writ large.

However, in all these examples there is a rigid body. The example of globular clusters tells of a mighty invisible framework behind the all too elusive phenomena. Newton knew it was there long before the astronomers found the grandest examples of its handiwork: spiral galaxies. In them, the initially invisible effects of the framework have become visible. Indeed, any isolated collection of matter, whatever its nature – a million stars in a globular cluster or a huge cloud of dust in space – has its associated fixed axis of net spin. Laplace called the plane perpendicular to it through the centre of mass the invariable plane , because its orientation can never change. Sometimes it can actually be seen. This is because some motions can be changed or even lost through mutual interactions, whereas others cannot. For example, objects moving parallel to the spin axis in opposite directions may collide and be deflected into the invariable plane. Over time, the matter in the system can ‘collect’ in or near it provided there is still the correct amount of circular motion about the axis. This has happened in spiral galaxies, in which the bright stars in the spiral arms are formed from such accumulated matter. They ‘light up’ the invariable plane, making it visible (Figure 15).

A similar effect has been at work in the solar system. About four and a half billion years ago the Sun and planets formed from a huge cloud of dust left over from a supernova explosion. The dust had some net spin, and an associated invariable plane. The Sun formed near the cloud’s centre of mass, and gathered up most of the mass in the cloud. More or less all of the solar system’s rotation now takes place in the plane of the ecliptic, in which the Earth moves around the Sun. Although the Sun got the bulk of the mass, Jupiter has most of the spin.

Figure 15.A spectacular spiral galaxy seen ‘from above’.

The fact that all the planets move in the same direction around the Sun in nearly coincident planes is thus a remote consequence of the relatively modest initial net spin of the primordial dust cloud. We see the result in the sky, since all the celestial wanderers – the Sun, Moon and planets – follow much the same track against the background of the stars. Ironically, Newton underestimated the power of his own laws. He could not bring himself to believe that the solar system had arisen naturally. ‘Mere mechanical causes’, he said, ‘could not give birth to so many regular motions.’ He asserted that ‘this most beautiful system’ could only have proceeded ‘from the counsel and dominion of an intelligent and powerful Being’. One wonders what Newton would have made of the modern pictures of Saturn and its rings (Figure 16). Of all the images created in the heavens by gravity and the invariable plane, this is surely the most perfect.

For three centuries, the best explanation for phenomena like the rings of Saturn has remained Newton’s: inertia, the inherent tendency of all objects to follow straight lines in the room-like arena of absolute space. If these are accepted, then the rings of Saturn, tops, frisbees and all the other manifestations of angular momentum can be explained. However, Newton’s account is not so much an explanation as a statement of facts in need of explanation. Since it is always matter that we actually see, should we not try to account for these things without the mysterious intermediaries of absolute space and time? Before we attack this problem, we need to consider energy and, in the next chapter, clocks and the measurement of time.

Figure 16.Saturn and its rings.

Energy is the most basic quantity in physics. It comes in two forms: kinetic energy measures the amount of motion in a system, while potential energy is determined by its instantaneous configuration. Like angular momentum, in an isolated system the sum of the two remains constant. If one decreases, the other must increase. For example, the potential energy of a falling body is proportional to its height and decreases as it falls. The speed of descent, and with it the kinetic energy, increases by an exactly compensating amount.

Energy, like the whole of mechanics, has a curious hybrid nature. Absolute space and time are needed to calculate kinetic but not potential energy. Each body of mass m and speed v in a system contributes a kinetic energy ½ mv 2 . The speed is measured in absolute space, which is why it is needed to calculate kinetic energy. By contrast, the potential energy of a system depends only on its relative configuration. For example, each pair of gravitating bodies in a system contributes to the system’s total potential energy an amount that is inversely proportional to their separation. If this is doubled, the potential energy of the pair is halved. Since each point in any Platonia corresponds to a different configuration of bodies, the potential energy changes from place to place in Platonia. This is illustrated for three bodies in Figure 17.
